General:

This compact measuring current transformer is designed to comply with BSEN/IEC60044-1 regulations and follow international trends in control gear/switchgear design and kilowatt-hour metering.

Clean and uniform in appearance and are entirely enclosed in impact and heat resisting housings. The moulded apertures allow transformers to be rapidly and firmly clamped or wedged to metric or inch busbars. Low cost busbar fixing devices are available, thereby eliminating the necessity for costly and complicated mounting angles. All terminal fitting are manufactured from plated brass and are grooved to ensure excellent contact pressure. Available in accuracy classes ranging from 0.2s to 5, and are fully tested using modern and highly accurate test equipment prior to despatch.

Model M40
Primary Current Range Primary Accomodation

Unit Dimensions

(L x W x H) mm

Maximum VA at Accuracy Class
Class 3 Class 1 Class 0.5
75A

30mm dia hole

40 x 13mm Busbar



75 x 32 x 105 1.5 - -
80A 2.5 - -
100A 5 1.5 -
120A 5 2.5 -
150A 7.5 2.5 -
200A 10 5 2.5
250A 10 10 5
300A 15 10 5
400A 15 10 10
500A 15 15 10
600-800A 15 15 15
Available with 1A or 5A Secondary
