Model R102
Ratio ID OD VA Axial Length (mm) For Accuracy Class
Class 3 Class 1 Class 0.5
200/5A or 1A 102 135 2.5 17 30 57
5 32 32 -
10 42 47 -
15 58 - -
250/5A or 1A 102 135 2.5 17 42 42
5 32 30 60
7.5 32 47 -
10 42 60 -
15 58 60 -
300/5A or 1A 102 135 2.5 17 42 47
5 32 42 62
7.5 32 60 62
10 32 42 -
15 42 42 -
400/5A or 1A 102 135 5 17 32 58
7.5 17 32 60
10 32 42 60
15 32 58 60
500/5A or 1A 102 135 5 32 32 58
10 32 32 58
15 32 42 52
600/5A or 1A 102 135 5 17 17 42
10 32 32 42
15 32 32 45
750/5A or 1A 102 135 5 17 17 32
10 17 17 32
15 32 32 32
800/5A or 1A 102 135 5 17 17 32
10 17 17 32
15 32 32 32
1000/5A or 1A 102 135 5 17 17 17
10 17 17 17
15 17 17 32
1200/5A or 1A 100 175 10 18 18 18
15 18 18 35
1250/5A or 1A 100 175 10 18 18 18
15 18 18 35
1500/5A or 1A 100 135 15 20 20 20
1600/5A or 1A 100 135 15 20 20 20
2000/5A or 1A 100 137 15 23 23 23
2400/5A or 1A 97 140 15 23 23 23
2500/5A or 1A 97 140 15 23 23 23
3000/5A or 1A 93 145 15 25 25 25




Ordering Information
Required Information Example
Ratio 1000/5A
VA 10VA
Accuracy Class Class 0.5
Limit Factor
Minimum Inside Diameter 100mm
Assmbley Style RT Terminals
Assmbley Style RLx Ring with Leads 1Metre (RL1M)
Assmbley Style RTS Ring with Terminals & Screws
Assmbley Style RTF Ring with Terminals & Frame
Assmbley Style RTC Ring with Terminals & Busbar Clamp
Assembley Styles Multiple configuration RTFS
